Maximizing Security with Dahua Cameras: Comprehensive Features Explained

Maximizing Security with Dahua Cameras: Comprehensive Features Explained

Maximizing Security with Dahua Cameras: Comprehensive Features Explained.In the security landscape, continuous advancement is a critical necessity. Dahua Technology, a global leader in surveillance, embodies this commitment by providing a broad range of smart surveillance options tailored for diverse environments from urban residential areas to large-scale industrial sites. Dahua’s surveillance systems deliver unmatched security capabilities, utilizing state-of-the-art technologies to ensure your safety and peace of mind.

Cutting-Edge Technologies at the Forefront

Central to Dahua’s offerings are the innovative Dahua WizMind Series, including the WizMind S and WizMind X series. These products utilize advanced deep learning algorithms to enable precise audio and visual analytics. This progressive approach enhances operational efficiency and maintains high accuracy, crucial for environments where stringent surveillance is required.

Dahua WizMind S Series: Smart and Sturdy

Dahua’s WizMind S Series is renowned for its intelligent features that seamlessly integrate with varied security needs. This series offers an extensive array of functionalities such as video metadata, acute sound detection, facial recognition, and perimeter defense, providing all-encompassing surveillance and proactive security. Equipped with AI-Enhanced Imaging and Deeplight capabilities, it ensures superior image clarity in dimly lit conditions. With durability certifications like IP67 and IK10, the S Series is perfectly suited for external environments where exposure to elements is a frequent challenge.

Dahua WizMind X Series: Broad-Spectrum Surveillance

Building on the S Series, the Dahua WizMind X Series offers expanded capabilities to accommodate a wider variety of settings with its sophisticated recognition technologies. This series excels in distinguishing between humans, motorized vehicles, and non-motorized vehicles, bolstering security in both private and public sectors. It also supports advanced face recognition, personal protective equipment detection, and automatic number plate recognition, indispensable for regions requiring rigorous monitoring and safety adherence. The X Series also meets high durability standards and performs reliably in tough conditions.

DAHUA IPC-HDBW5842R-ASE 8MP IR Fixed-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5842R-ASE
IPC-HDBW5842R-ASE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HF5842F-ZE 8MP Box WizMind Network Camera

IPC-HF5842F-ZE
IPC-HF5842F-ZE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> 12 VDC power output, and max. current 165 mA, easy for installation.

> SMD 3.0.

DAHUA IPC-HFW5842T-SE 8MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5842T-SE
IPC-HFW5842T-SE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5842T-ASE 8MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5842T-ASE
IPC-HFW5842T-ASE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDW5842T-ZE 8MP IR Vari-focal Eyeball WizMind Network Camera

IPC-HDW5842T-ZE
IPC-HDW5842T-ZE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HDW5842TM-ASE 8MP IR Fixed-focal Eyeball WizMind Network Camera

IPC-HDW5842TM-ASE
IPC-HDW5842TM-ASE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HFW5842H-Z4HE 8MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5842H-Z4HE
IPC-HFW5842H-Z4HE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.

DAHUA IPC-HFW5842H-ZHE 8MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5842H-ZHE
IPC-HFW5842H-ZHE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.

DAHUA IPC-HDBW5842H-Z4HE 8MP IR Vari-focal Dome WizMind Network Camera

IPC-HDBW5842H-Z4HE
IPC-HDBW5842H-Z4HE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.

> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.

DAHUA IPC-HDBW5842H-ZHE 8MP IR Vari-focal Dome WizMind Network Camera

IPC-HDBW5842H-ZHE
IPC-HDBW5842H-ZHE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.

DAHUA IPC-HFW5842E-ZHE 8MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5842E-ZHE
IPC-HFW5842E-ZHE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

>Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

DAHUA IPC-HFW5842E-Z4E 8MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5842E-Z4E
IPC-HFW5842E-Z4E

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0

DAHUA IPC-HFW5842E-ZE 8MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5842E-ZE
IPC-HFW5842E-ZE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5842E-ASE 8MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5842E-ASE
IPC-HFW5842E-ASE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HDBW5842E-ZHE 8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5842E-ZHE
IPC-HDBW5842E-ZHE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

DAHUA IPC-HDBW5842E-Z4E 8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5842E-Z4E
IPC-HDBW5842E-Z4E

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDBW5842E-ZE 8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5842E-ZE
IPC-HDBW5842E-ZE

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HF5541F-ZE 5MP Box WizMind Network Camera

IPC-HF5541F-ZE
IPC-HF5541F-ZE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.

> Supports P-iris, the camera can control the iris more precisely for better image effect.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> SMD 3.0.

DAHUA IPC-HDW5541T-ZE 5MP IR Vari-focal Eyeball WizMind Network Camera

IPC-HDW5541T-ZE
IPC-HDW5541T-ZE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HFW5541E-ZHE 5MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5541E-ZHE
IPC-HFW5541E-ZHE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

DAHUA IPC-HFW5541E-Z5E 5MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5541E-Z5E
IPC-HFW5541E-Z5E

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5541E-ZE 5MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5541E-ZE
IPC-HFW5541E-ZE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0

DAHUA IPC-HDBW5541E-ZHE 5MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5541E-ZHE
IPC-HDBW5541E-ZHE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

DAHUA IPC-HDBW5541E-Z5E 5MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5541E-Z5E
IPC-HDBW5541E-Z5E

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDBW5541E-ZE 5MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5541E-ZE
IPC-HDBW5541E-ZE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5541E-ASE 5MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5541E-ASE
IPC-HFW5541E-ASE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960×1668) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HFW5541T-SE 5MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5541T-SE
IPC-HFW5541T-SE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5541T-ASE 5MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5541T-ASE
IPC-HFW5541T-ASE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960×1668) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDBW5541R-ASE 5MP IR Fixed-focal Dome WizMind Network Camera

IPC-HDBW5541R-ASE
IPC-HDBW5541R-ASE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDW5541TM-ASE 5MP IR Fixed-focal Eyeball WizMind Network Camera

IPC-HDW5541TM-ASE
IPC-HDW5541TM-ASE

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960 × 1668) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HF5442F-ZE 4MP Box WizMind Network Camera

IPC-HF5442F-ZE
IPC-HF5442F-ZE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> 12 VDC power output, and max. current 165 mA, easy for installation.

> SMD 3.0.

DAHUA IPC-HFW5442T-ASE 4MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5442T-ASE
IPC-HFW5442T-ASE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5442T-SE 4MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5442T-SE
IPC-HFW5442T-SE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDW5442T-ZE 4MP IR Vari-focal Eyeball WizMind Network Camera

IPC-HDW5442T-ZE
IPC-HDW5442T-ZE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HDW5442TM-ASE 4MP IR Fixed-focal Eyeball WizMind Network Camera

IPC-HDW5442TM-ASE
IPC-HDW5442TM-ASE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30fps

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HDBW5442R-ASE 4MP IR Fixed-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5442R-ASE
IPC-HDBW5442R-ASE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30fps

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5442H-Z4HE 4MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5442H-Z4HE
IPC-HFW5442H-Z4HE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

DAHUA IPC-HFW5442H-ZHE 4MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5442H-ZHE
IPC-HFW5442H-ZHE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.

DAHUA IPC-HDBW5442H-Z4HE 4MP IR Vari-focal Dome WizMind Network Camera

IPC-HDBW5442H-Z4HE
IPC-HDBW5442H-Z4HE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.

DAHUA IPC-HDBW5442H-ZHE 4MP IR Vari-focal Dome WizMind Network Camera

IPC-HDBW5442H-ZHE
IPC-HDBW5442H-ZHE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.

DAHUA IPC-HFW5442E-ZHE 4MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5442E-ZHE
IPC-HFW5442E-ZHE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

DAHUA IPC-HFW5442E-Z4E 4MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5442E-Z4E
IPC-HFW5442E-Z4E

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5442E-ZE 4MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5442E-ZE
IPC-HFW5442E-ZE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5442E-ASE 4MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5442E-ASE
IPC-HFW5442E-ASE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30fps

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HDBW5442E-ZHE 4MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5442E-ZHE
IPC-HDBW5442E-ZHE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

DAHUA IPC-HDBW5442E-Z4E 4MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5442E-Z4E
IPC-HDBW5442E-Z4E

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDBW5442E-ZE 4MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5442E-ZE
IPC-HDBW5442E-ZE

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HF5241F-ZE 2MP Box WizMind Network Camera

IPC-HF5241F-ZE
IPC-HF5241F-ZE

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.

> Supports P-iris, the camera can control the iris more precisely for better image effect.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> SMD 3.0.

DAHUA IPC-HDW5241T-ZE 2MP IR Vari-focal Eyeball WizMind Network Camera

IPC-HDW5241T-ZE
IPC-HDW5241T-ZE

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HFW5241E-Z12E 2MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5241E-Z12E
IPC-HFW5241E-Z12E

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 150 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK1

> SMD 3.0.

DAHUA IPC-HFW5241E-Z5E 2MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5241E-Z5E
IPC-HFW5241E-Z5E

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5241E-ZE 2MP IR Vari-focal Bullet WizMind Network Camera

IPC-HFW5241E-ZE
IPC-HFW5241E-ZE

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDBW5241E-Z5E 2MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5241E-Z5E
IPC-HDBW5241E-Z5E

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDBW5241E-ZE 2MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

IPC-HDBW5241E-ZE
IPC-HDBW5241E-ZE

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5241E-ASE 2MP IR Fixed-focal Dome WizMind Network Camera

IPC-HFW5241E-ASE
IPC-HFW5241E-ASE

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HFW5241T-SE 2MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5241T-SE
IPC-HFW5241T-SE

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HFW5241T-ASE 2MP IR Fixed-focal Bullet WizMind Network Camera

IPC-HFW5241T-ASE
IPC-HFW5241T-ASE

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDBW5241R-ASE 2MP IR Fixed-focal Dome WizMind Network Camera

IPC-HDBW5241R-ASE
IPC-HDBW5241R-ASE

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.

DAHUA IPC-HDW5241TM-ASE 2MP IR Fixed-focal Eyeball WizMind Network Camera

IPC-HDW5241TM-ASE
IPC-HDW5241TM-ASE

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.

DAHUA IPC-HDBW71242E1-Z-X 12MP IR Dome WizMind Network Camera

IPC-HDBW71242E1-Z-X
IPC-HDBW71242E1-Z-X

> 12-MP 1/1.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 12 MP (4000 × 3000)@25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).

DAHUA IPC-HFW71242H-Z-X 12MP IR Bullet WizMind Network Camera

IPC-HFW71242H-Z-X
IPC-HFW71242H-Z-X

> 12-MP 1/1.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 12 MP (4000 × 3000)@25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).

DAHUA IPC-HF71242F-Z-X 12MP Box WizMind Network Camera

IPC-HF71242F-Z-X
IPC-HF71242F-Z-X

> 12-MP 1/1.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 12 MP (4000 × 3000)@25/30 fps.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

DAHUA IPC-HF7842F-Z-X 8MP BOX WizMind Network Camera

IPC-HF7842F-Z-X
IPC-HF7842F-Z-X

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

DAHUA IPC-HDBW7842E1-Z4-X 8MP IR Dome WizMind Network CAMERA

IPC-HDBW7842E1-Z4-X
IPC-HDBW7842E1-Z4-X

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, flexible coding, applicable to various bandwidth and storage environments. · Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).

DAHUA IPC-HDBW7842E1-Z-X 8MP IR Dome WizMind Network CAMERA

IPC-HDBW7842E1-Z-X
IPC-HDBW7842E1-Z-X

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection:Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).

DAHUA IPC-HFW7842H-Z4-X 8MP IR Bullet WizMind Network Camera

IPC-HFW7842H-Z4-X
IPC-HFW7842H-Z4-X

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection.

> Anti-Corrosion coating(optional).

DAHUA IPC-HFW7842H-Z-X 8MP IR Bullet WizMind Network Camera

IPC-HFW7842H-Z-X
IPC-HFW7842H-Z-X

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection.

> Anti-Corrosion coating(optional).

DAHUA IPC-HF7442F-Z-X 4MP BOX WizMind Network Camera

IPC-HF7442F-Z-X
IPC-HF7442F-Z-X

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

DAHUA IPC-HDBW7442E1-Z4-X 4MP IR Dome WizMind Network Camera

IPC-HDBW7442E1-Z4-X
IPC-HDBW7442E1-Z4-X

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).

DAHUA IPC-HDBW7442E1-Z-X 4MP IR Dome WizMind Network CAMERA

IPC-HDBW7442E1-Z-X
IPC-HDBW7442E1-Z-X

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).

DAHUA IPC-HFW7442H-Z4-X 4MP IR Bullet WizMind Network Camera

IPC-HFW7442H-Z4-X
IPC-HFW7442H-Z4-X

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection.

> Anti-corrosion coating (optional).

DAHUA IPC-HFW7442H-Z-X 4MP IR Bullet WizMind Network Camera

IPC-HFW7442H-Z-X
IPC-HFW7442H-Z-X

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection.

> Anti-Corrosion coating(optional).

Sustainability and Collaborative Initiatives

Dahua is committed to sustainability, significantly reducing environmental impacts through efforts like adopting plastic-free, fully recyclable packaging. This dedication permeates all facets of our operations, showcasing our commitment to responsible corporate practices.

In partnership with CCTV-MALL, we deliver these advanced Dahua technologies directly to you. Our collaboration guarantees that clients receive the latest in surveillance innovations, supported by our shared commitment to quality and client satisfaction.

Conclusion: Enhance Your Security with Dahua and CCTV-MALL

Discover the capabilities of the Dahua WizMind Series and other products by visiting our specialized platform at www.cctv-mall.com. For tailored services and specific product details, contact us at sales@cctv-mall.com. Enhance your security setup with Dahua’s elite surveillance solutions, available through CCTV-MALL, ensuring comprehensive protection and advanced monitoring of your premises.

About The Author

Leave a comment

Leave a Reply

Your email address will not be published. Required fields are marked *

Related Articles

DAHUA Network Cameras: Your Reliable Surveillance Shield
BusinessIndustry technology

DAHUA Network Cameras: Your Reliable Surveillance Shield

In the ever-evolving domain of security technology, the quest for reliable and...

Maximizing Security with Dahua Cameras: Comprehensive Features Explained
Industry technology

Exploring the Diverse and Powerful Features of HIKVISION NVR Systems

Exploring the Diverse and Powerful Features of HIKVISION NVR Systems.Discover the array...

Dahua NVR: Enhancing Security Effectiveness with Cutting-Edge Features
ElectronicsIndustry technology

Dahua NVR: Enhancing Security Effectiveness with Cutting-Edge Features

In the ever-evolving landscape of security technology, Dahua’s Network Video Recorder (NVR)...
